An ISO 9001:2008 certified company, Bimal Aluminiums Pvt. Ltd. is a world's reputed manufacturer and exporter of dairy equipment such as Domestic Cream Separators, Electric Cream Separator, Aluminium Milk Storage and many others. These are manufactured using food grade material, which ensures their sanitary nature. Embracing the market challenges and new technologies, we have acquired capability of developing precision and compact designs of every product. The ambit of our domestic cream separators is manufactured using CNC machines, that are used for making its components. Also, we have made sure to dynamically balance the centrifugal bowl to ensure vibration free movement. This ambit includes electric cream separator which is made of stainless steel and other material. Their innovative design makes it possible to separate the milk cream from milk cautiously and swiftly. Since the material of construction of these separators is completely free from corrosion, there is no chance of milk getting contaminated. The Aluminium Milk Storage products or Aluminium Milk Cans are a one piece product having a long life and abrasion resistance. They are light in weight and comply with ISI guidelines.

Water Dispenser / Vending Machine

Water Dispenser /Vending Machine

With having large clientele around the world, we have established ourselves as a reliable manufacturer, exporter and supplier of Water Dispenser /Vending Machine in the market. The body of this Water Dispenser /Vending Machine is made of well chosen stainless steel. Equipped with necessary components like hot water tank, ice making water tank, temperature adjusting system and alarm facility, this energy efficient machine is a suitable way to get purified hot and cold water at the same time. Its advanced O purification mechanism provides germ free water within a short period.

Features
  • Uninterrupted UV sterilization system
  • LCD display facility
  • Easy to install
  • Water proof design
Bulk Milk Coolers

Bulk Milk Coolers

We are manufacturing and exporting durable bulk milk coolers of direct expansion type. These milk coolers / equipment are suitable for installation at village Dairy Cooperative Society. Here, milk is collected everyday, in morning and evening, from various producers of the milk. The collected milk is stored in bulk milk coolers, also called milk chillers. In these equipment, the milk is cooled to 4 degrees from the ambient temperature within the span of 3 hours. We design these milk chillers using latest designing software and other resources. The milk coolers/equipment are designed as per the ISO 5708-2A II quality standards.


Key Features:


  • This latest version of milk coolers/chillers takes not more than 3 hours to cool milk from 35 to 4 Degree C for the first milking, from 19.5 to 4 degree C for IInd milking and not more than 1.5 hours for a milking i.e. from 10 to 4 degree c.
  • Tank is made of AISI 304 SS
  • Tank's thickness is enough to ascertain robustness, durability & adaptability
  • Top class condensing unit, compressor, agitator motor and other parts are used
  • Trouble-free service

Salient Features :

  • Faster cooling owing to direct expansion
  • Conforms to ISO 5708 2A II- latest version
  • Robust design
  • Durable tank made of AISI 304 SS
  • Hermetically sealed compressor
  • Digital temp controller
  • Occupy minimum space
  • Energy conscious
  • Designed to be user friendly

Technical Specifications

Particulars

500 LTR

1000 LTR

2000 LTR

5000 LTR

Model/Type of tank

BI-DX-CV

BI-DX-CV

BI-DX-HCL

BI-DX-HCL

Rated capacity

500LTR

1000 LTR

2000 LTR

5000 LTR

Gross capacity

550LTR

1100LTR

2200LTR

5500LTR

Thermo plate

IMPORTED

IMPORTED

IMPORTED

IMPORTED

Construction material

AISI 304 SS

AISI 304 SS

AISI 304 SS

AISI 304 SS

S.s thick inner

2 MM

2 MM

2 MM

2 MM

S.s thick outer

1.5 MM

1.5 MM

1.5 MM

1.5 MM

Milk measuring facility

DIP STICK

DIP STICK

DIP STICK

DIP STICK

Agitator rpm/number

21/1

21/1

21/1

21/1

Insulation density

40KG/CU.M

40KG/CU.M

40KG/CU.M

40KG/CU.M

Thickness of insulation

50 MM

50 MM

50 MM

5 MM

Make of compressor

Kcl/Denfoss

Kcl/Denfoss

Kcl/Denfoss

Kcl/Denfoss

Model of compressor

CR-22

CR-36

CR-36

572

Cooling capacity

2520Kcl/hour

5310Kcl/per hour

10620 Kcl/per hour 2Xcr-36

30240 Kcl/per hour 2X 572

Type of refrigerant

R-22

R-22

R-22

R-22

Ambient tem

AS PER ISO 5708 II A

AS PER ISO 5708 II A

AS PER ISO 5708 II A

AS PER ISO 5708 II A

Maximum cooling time

3.0 Hours

3.0 Hours

3.0 Hours

3.0 Hours

Temp range considered

35->4C

35->4C

35->4C

35->4C

Power requirement

Single/Three phase

Single/Three phase

Single/Three phase

Three phase

Connected load

1600Watts

2480 Watts

4960 Watts

13040 Watts

We are a prestigious company, established as the manufacturer and exporter of dairy equipment. We specialize in undertaking Milk Turnkey Projects as per the specifications of clients. Herein, we can design, manufacture, install and commission Skid Mounted Pasteurizer Plant, Sauce Pot and other products. The entire project is undertaken with the commitment to bring out the most positive results that will benefit customers for many years to come. We carefully plan the entire process with important considerations to different aspects of client's constraints such as scale of operation, types of machinery required, level of automation needed and others. This enables us to ensure 100% inefficiency in the Milk Turnkey Projects for Skid Mounted Pasteurizer Plant, Sauce Pot and others.

Skid Mounted Pasteurizer Plant

Skid Mounted Pasteurizer Plant 500 LPH

We are one of the established manufacturers and suppliers of a wide assortment of pasteurizers. We make use of latest technology available for our range, to leave no stone unturned in offering an immaculate range of dairy process equipment. Precisely designed and developed these pasteurizers are very safe and secure to use and are also easy to maintain. Further, these are available in various capacities as per the choices of our clients.

Skid Mounted Plant

Skid Mounted Pasteurization Plant 10KL

We offer an excellent range of Skid Mounted Pasteurization Plant that is designed and developed by experts by using latest technology. Their regeneration efficiency is more than 90% and Capacity is 10 KL. Precisely engineered these are very safe to operate and maintain.

Aluminium Lockable Milk Cans

Aluminium Lockable Milk Cans

"BIMAL" is a popular name in the segment of Aluminium Lockable Milk Cans that are used for the prevention of theft of milk while its transportation. These Lockable Milk Cans are manufactured in different capacities but have a single piece construction. This ensures no leakage of milk at any stage of use. Also, the lockable features makes sure that no one can tamper with the original milk and that the milk is protected from harmful environment factors like dust etc. Our Aluminium Lockable Cans are portable and are developed on the basis of the guidelines of ISI.

Few attributes of our Milk Cans are as follows:

  • 'Bimal' Aluminium Lockable Milk Cans is the only Milk Can in India that is made on : (i) Automated Imported "German Machine" (ii) With stainless Steel Dies.
  • The smoothness of its interior walls is at part with excellence, when compared to the other brands present in India.
  • The cans are manufactured from raw material that are brought from Hindalco Industries Ltd.
  • ISI mark
  • Sturdy anodized construction which is capable of withstanding scratches.
  • At 5 points, the spot welded lids are present. This brings uniformity in the life span of lids and milk cans.
  • Longer operational durability: high ductility, high tensile strength, high yield point and relatively high hardness
  • Shrink fit bottom bend with extra smooth MIG welding all round
  • Smoothly brazed handles
  • The Lockable Milk Cans have a strong (solid) neck bedding. This is one factor which adds to its wear resistance at the mouth.
  • They have over 85 BHN hardness. This directly benefits in the form of high wear resistance and high ductility to both mechanical and abrasion deformation.





Aluminium Milk CansTo prevent ourselves being between a rock and a hard place, we have updated our manufacturing setup for Aluminium Milk Cans. The setup is in existence since 1979, the time from which we are serving the needs of dairy industry and dairy farmers. The range of ISI marked Aluminium Alloy Milk Can is checked for being in conformity with the Indian standard IS-1825:1983. These milk cans are the only ones in India that are made with stainless steel dies and automated imported "German Machine" The material used in its manufacturing are brought from Hindalco Industries Ltd. which is an ISO-9001 certified company. Few of the key features of this product are:
  • Excellent smoothness of inside wall
  • Handles are smoothly brazed
  • Shrink fit bottom bend that have extra-smooth MIG Welding throughout it
  • Its mouth has string wear resistance due to the presence of strong (solid) neck bedding
  • It can withstand scratches as it is sturdily anodized
  • The life of milk cans and its lid is similar as the lid is spot welded at 5 times
  • The milk cans have over 85 BHN hardness that bestows it with high ductility as well as high wear resistance against abrasion as well as mechanical deformation.
  • High ductility
  • High tensile strength
  • High yield point
  • Longer operational durability
  • Relatively high hardness
Bimal Aluminiums Pvt. Ltd. is a ISO 9001:2008 certified company and an acknowledged manufacturer and exporter of dairy equipments. The range of Aluminium Dairy Equipments is made using material brought from recognized companies, holding reputed quality certification. The range of Dairy Processing Equipments offered by us includes Heating Vat, Ghee Clarifier, Ghee Boiler, Cream Separator, Cooling Cabinet, Cheese Press and many others. The production processes of dairy equipment are upgraded whenever we find a new and better technology that could enhance the quality of our products, along with reducing the overall manufacturing cost. The prerequisites for successful business are considered as fruitful co-operation with associates and customers - one of the areas where BIMAL possess specialization in.

Heating Vat

Heating Vat

We have with us rich industry experience in successfully meeting the requirements of Heating Vats. These are well recognized for their superior process efficiency and can be delivered in Mild Steel, Stainless Steel, Titanium, PTFE options. We can also customize these as per the application requirements at client’s end.

Ghee Line - Ghee Kettle

Ghee Line - Ghee Kettle

We also hold expertise in offering Ghee Kettles for Ghee Lines. These comprise of three jacket finish that is precision fabricated using SS 304 material. The inner jacket designed is closed by hemispherical dish and is covered from top and bottom. Further, the plate thickness and volume of vessel can be selected to suit desired pressure requirements. The outer jacket is steam jacket and is fabricated from SS material. This jacket features steam inlet, safety valve connection and condensate outlet and allows steam to be distributed in jacket with help of pipe. Finally, the kettle is insulated by glass wool insulation and cladded with SS sheet.
